US Perfect Auto Parts & Supplies Inc.
Cummins ISX15 HE451VE 3792574 turbocharger with actuator

HE451VE 3792574 Turbocharger with Actuator for Cummins ISX15 450-500HP

This HE451VE ships as a complete unit with the VGT electric actuator mounted and calibrated - no actuator transfer, no INSITE setup on the old unit. It fits 2009+ Cummins ISX15 CM570 and QSX engines rated 450-500HP, replacing OE 3792574 / 2882111 / 3767305. New, dynamically balanced, no core charge, with volume pricing for shops and fleets.

Turbo Model

Holset HE451VE (VGT, supplied with electric actuator installed and calibrated)

OEM / Interchange Numbers

2882111RX, 2882111, 2841220, 3792574, 3795144, 3773561, 3767305, 2841221

Application

2009+ Cummins ISX15 CM570 and QSX engines, 450HP-500HP ratings

Service & Support

  • 1-Year Warranty
  • US Stock, Fast Dispatch
  • Bulk Orders Welcome
Get a Quick Quote

Your Source for Quality Diesel Engine Parts

  • US stock fast dispatch icon
  • 100% brand new parts icon
  • 1-year warranty icon
  • Wholesale pricing icon
  • White-label support icon
  • Fully certified quality icon

FAQ

2009+ Cummins ISX15 CM570 and QSX engines, 450HP-500HP ratings

It replaces 2882111RX, 2882111, 2841220, 3792574, 3795144, 3773561, 3767305, 2841221. If your number is not listed, send it with the old part's dataplate photo and we confirm the match before shipping.

Brand new — new components throughout, not remanufactured. No core deposit and nothing to return.

A 1-year unlimited-mileage warranty against material and workmanship defects, handled directly by our US-based team. Details on the warranty and after-sales page.

Yes. Shops, fleets and resellers get consistent wholesale pricing from US inventory, with white-label support for distributors. Send the part number and quantity for a quote.

HE451VE 3792574 Turbocharger with Actuator for Cummins ISX15 450-500HP — Product Details

  • OE / Interchange Numbers: 2882111RX, 2882111, 2841220, 3792574, 3795144, 3773561, 3767305, 2841221
  • Application: 2009+ Cummins ISX15 CM570 and QSX engines, 450HP-500HP ratings
  • Condition: Brand new — not remanufactured, no core charge
  • Warranty: 1-year unlimited-mileage, handled by our US team
  • Stock: US warehouse inventory, orders processed within 24 hours

Need more than one? We supply shops, fleets and resellers at consistent wholesale pricing, with white-label support for distributors. Send the part number for a volume quote — see the wholesale program and our warranty policy.

Cross Reference Numbers

This turbocharger replaces the following OE and interchange numbers:

  • 2882111 / 2882111RX
  • 3792574 / 3795144
  • 2841220 / 2841221
  • 3773561 / 3767305

Related numbers: without-actuator version and the 550HP variant 2882112.

Installation and Care

  • Find out why the old turbo failed before installing the new one. Oil starvation or contaminated oil will destroy the replacement the same way.
  • Change the engine oil and filter. Flush or replace the oil feed line.
  • Prime the turbo with clean oil before first startup. Crank the engine with fuel disabled until oil pressure builds.
  • The VGT actuator is mounted and calibrated - plug in and go. Do not swap actuators between units.
  • Idle for several minutes after installation to establish oil pressure and check for leaks before applying load.
  • Ships with mounting gaskets. Torque fasteners to the Cummins service manual spec.

See our quality process for details.
